SHOULDER EYEBOLTS
- Forged. C-1030 carbon steel, self color
- Do not use Eye Bolts on angular lifts
- Always apply Eye Bolt loads in the plane of the eye
- Seat Shoulder Eye Bolts firmly against material part
- Do not exceed safe working load of rated capacity
- Fit all Eye Bolts firmly and tightly in the hole and check them
- Do not paint or coat Eye Bolts. Inspection is difficult if painted
- Engage full thread to obtain capacity rating
- Add one half turn to align plane of Eye Bolt
SPECIFICATIONS:
| Part No. | Thread Size (A) | Shank Length (B) | Eye I.D. (C) | O.D. Eye (D) | Overall Length (E) | Safe Working Load | Weight |
|---|---|---|---|---|---|---|---|
| 83001 | 1/4″ – 20 | 1″ | 3/4″ | 1-3/16″ | 2-1/2″ | 500 LBS | 0.1 LBS |
| 83002 | 5/16″ – 18 | 1-1/8″ | 7/8″ | 1-7/16″ | 2-7/8″ | 900 LBS | 0.1 LBS |
| 83003 | 3/8″ – 16 | 1-1/4″ | 1″ | 1-21/32″ | 3-9/32″ | 1,300 LBS | 0.2 LBS |
| 83004 | 1/2″ – 13 | 1-1/2″ | 1-3/16″ | 2-1/16″ | 4-1/32″ | 2,400 LBS | 0.4 LBS |
| 83005 | 5/8″ – 11 | 1-3/4″ | 1-3/8″ | 2-1/2″ | 4-25/32″ | 4,000 LBS | 0.7 LBS |
| 83006 | 3/4″ -10 | 2″ | 1-1/2″ | 2-13/16″ | 5-3/8″ | 5,000 LBS | 1.1 LBS |
| 83007 | 7/8″ – 9 | 2-1/4″ | 1-11/16″ | 3-1/4″ | 6-1/8″ | 7,000 LBS | 1.7 LBS |
| 83008 | 1″ – 8 | 2-1/2″ | 1-13/16″ | 3-9/16″ | 6-13/16″ | 9,000 LBS | 2.4 LBS |
