TYPE 6 – RETURN EYE (reversed eye) web sling is formed by using multiple widths of webbing held edge to edge. A wear pad is attached on one or both sides of the web sling body, and on both sides of the loop eyes to form a loop eye at each end. which is at a right angle to the plane of the web sling body.
The RETURN EYE sling can be used with all three hitch types, but it particularly well suited to the choker hitch due to the “TWISTED EYE”
Polyester webbing breaking strength: 9,800LBS / inch Safety Factor: 5:1
| 1 Ply | Vertical Lift (lbs) | Choked Lift (lbs) | Basket Lift (lbs) | Eye Width (inch) |
Eye Length (inch) |
Min. Standard Length (ft) |
| Sling Body Width | ||||||
| 2″ | 3,100 | 2,480 | 6,200 | 1″ | 10″ | 3′ |
| 4″ | 6,200 | 4,960 | 12,400 | 2″ | 12″ | 4′ |
| 6″ | 8,800 | 7,040 | 17,600 | 3″ | 14″ | 6′ |
| 2-Ply | Vertical Lift (lbs) | Choked Lift (lbs) | Basket Lift (lbs) | Eye Width (inch) |
Eye Length (inch) |
Min. Standard Length (ft) |
| Sling Body Width | ||||||
| 2″ | 6,200 | 4,960 | 12,400 | 1″ | 12″ | 4′ |
| 4″ | 11,000 | 8,800 | 22,000 | 2″ | 16″ | 6′ |
| 6″ | 16,500 | 13,200 | 33,000 | 3″ | 18″ | 6′ |
